    2.1 inch 480*480 300 brightness 24PIN MIPI IPS LCD display can be equipped with touch

    Ask Lasest Price
    Brand Name : HuaXin
    Model Number : ESHXT021003 V1.0-RF
    Certification : ISO14001/ ISO9001/IATF16949
    Price : $3-$5
    Payment Terms : T/T
    Supply Ability : 500K pcs per month
    Delivery Time : 4~6weeks
    • Product Details
    • Company Profile

    2.1 inch 480*480 300 brightness 24PIN MIPI IPS LCD display can be equipped with touch

    ESHXT021003 V1.0-RF is 2.1 inch 480*480, 300 brightness 24PIN MIPI IPS LCD can be equipped with touch (TFT LCD for life, home appliances, toys, medical products)
    Technical Specifications
    Display TechnologyTFT module
    Display Size2.1 inch
    Resolution480 * 480
    InterfaceMIPI
    Brightness300 cd/m²
    View AngleAll
    Drive ICST7701S
    Part No.ESHXT021003 V1.0-RF
    Working Temperature-20°C to 70°C
    Storage Temperature-30°C to 80°C
    Product Images

    Manufacturer Advantages
    • Cost-effective production facility in inland China
    • Advanced equipment ensuring stable product quality
    • Automated manufacturing processes for efficiency and consistency
    • Experienced engineering team with 20+ years in LCD technology
    • Custom design capabilities for specialized requirements
    About Huaxin Technology (Enshi) Co., LTD
    Established in 2009 and located in Hubei Enshi, Huaxin Technology is a high-tech enterprise specializing in LCD, LCM, TFT, backlight, and OLED research, development, and production.
    Product Range
    • VA, TN, HTN, STN, FSTN, CSTN LCD series
    • COB, TBA, COG, TP, LED backlight LCM series
    Company Details
    Registered capital20 million
    Staff500+ (10% R&D, 15% QC)
    CertificationsISO14001, ISO9001/IATF16949, SGS
    Production Capacity (k/Day)
    Product20212022202320242025
    LCD4.59999
    LCM70150300450450
    Backlight100200300500500
    OLED1020304050
    Applications
    • Car navigation systems & printers
    • Video communication & advertising displays
    • Automotive & medical devices
    • Fitness equipment & handheld devices
    • Industrial control systems & home appliances
    TFT Display Characteristics
    • Excellent image quality with high resolution and color accuracy
    • Fast response times for smooth transitions
    • Wide viewing angles with minimal color shift
    • Energy efficient operation
    • Available in various sizes for different applications
    • LED backlighting for consistent illumination
    TFT Display Limitations
    • Viewing angles may be limited compared to other technologies
    • Moderate contrast ratios
    • Backlighting increases power consumption
    • Potential motion blur in fast-moving content
    • Limited flexibility in physical form
    • Color gamut may be narrower than some alternatives
